Breadboard

Schematic / DRV8912      The 1748 is a DRV8912 12 channel SPI controlled HBridge driver mounted on a solderless breadboard adapter with a 0.500" row spacing.   LOGIC SPECS: Logic voltage (VDD): 3.0 to 5.5VDC SPI clock speed:...

     The 1402 is a small 19 x 14 hole x 0.10" pitch perf board for prototyping small through hole and SMT circuits. Note: When prototyping with ceramic capacitors, avoid using large amounts of solder on the end terminations! It is common...

     The 1472 is a small 39 x 39 pad x 0.05" pitch "Squares" board for prototyping small SMT circuits: The pad spacing is perfect for 0402 and 0603 chip components as well as 0.05" pitch SOIC ICs and SMT transistors. The back side is bare...

Schematic / Timing      The 1749 is an 4 channel 2.5 to 21 volt full bridge driver that is controlled from an 8 bit parallel data bus using a 74HC573 transparent latch which allows the outputs to all be updated at the same time. When...

Schematic      The 1747 is an adapter to allow the 1722 8x8 core matrix to be prototyped on a solderless breadboard.  The 1722 plugs into the 2mm sockets on the top side and the signals are fanned out to 0.10" pitch headers with a row...

Schematic / Core Specifications Features: These modules consist of 64 1.25mm OD x 0.70mm ID x 0.40mm Height square loop ferrite cores wired in an 8x8 matrix. Based on the 1722 footprint but signals fanned out to 0.10" pitch headers with a row to row...

Schematic      The 1571 is a 16 pin SMT prototyping board for use on solderless breadboards with 0.10" pin pitch with 0.50" row spacing. The underside is  a copper plane with 4 connection vias at the corners but no connection to any...

Schematic       Processor not included (Buy with PIC installed).      The 1746 is a breadboard adapter for PIC processors in the 28 pin 6x6mm QFN package. The QFN signals are fanned out to a 100 mil pin pitch by 500 mil...

Schematic       Processor included: When ordering, select the desired processor from the table at the bottom of this page and indicate the part number in the order notes (All parts are I suffix industrial grade). If the device you...
