8x8 magnetic core memory matrix breadboard adapter

Schematic

     The 1747 is an adapter to allow the 1722 8x8 core matrix to be prototyped on a solderless breadboard.  The 1722 plugs into the 2mm sockets on the top side and the signals are fanned out to 0.10" pitch headers with a row to row spacing of 0.90" which exposes one row of breadboard tie points on either side of the adapter.
